Specifications

POWERTRAIN - KOHLER EKT750

ENGINE	KOHLER EKT750
HORSEPOWER	27 EF
FUEL CAPACITY	10 GAL
GROUND SPEED	10 MPH
DISPLACEMENT	747 CC
CRANKSHAFT	VERTICAL
COOLING SYSTEM	AIR
CLUTCH	ELECTROMAGNETIC
FUEL TYPE	GASOLINE
TRANSMISSION	HYDRO-GEAR ZT-3400

POWERTRAIN - KAWASAKI FX730

ENGINE	KAWASAKI FX730
HORSEPOWER	23.5
FUEL CAPACITY	10 GAL
GROUND SPEED	10 MPH
DISPLACEMENT	726 CC
CRANKSHAFT	VERTICAL
COOLING SYSTEM	AIR
CLUTCH	ELECTROMAGNETIC
FUEL TYPE	GASOLINE
TRANSMISSION	HYDRO-GEAR ZT-3400

GROUND FORCE DECK

CUTTING HEIGHT	1.5" - 4.5"
SPINDLE SPECS	FORGED ALUMINUM HOUSING W/ SEALED BALL BEARINGS
BLADE TIP SPEED	18,000 FT/MIN
DECK THICKNESS	10 GA W/11 GAUGE REINFORCED SPINDLE MOUNT
BLADE SPECS	.203 STRAIGHTENED & HARDENED STEEL
DECK SIZE	54" & 60"

OPERATOR'S STATION

BACKREST	18" SEAT BACK
ROLLOVER PROTECTIVE STRUCTURES (UP/DOWN)	70" /46.3"
ARM REST	PADDED ARM RESTS
SUSPENSION	MECHANICAL
TRACK	6" LOCKING TRACK
COVER	DURABLE SEWN VINYL COVER
STEERING CONTROLS	1.5" DIA GRIPS, ADJUSTABLE, DAMPENED
PARKING BRAKE	INTEGRATED INTO STEERING LEVERS

CONSTRUCTION

FRONT TIRES	13" X 6.5" X 6" FLAT - FREE
OVERALL LENGTH	74 3/4
REAR TIRES	23" X 12" - 12R
FEATURES	REINFORCED FORMED FRAME
FRAME GAUGE	7 GAUGE
OVERALL WIDTH (CHUTE UP)	54" - 54.75 - 60" - 60.75"
CASTER FORKS	3/8" FORMED
WEIGHT	54" - 1040 LBS . 60" - 1060 LBS | 54" - 1030 LBS · 60" - 1050 LBS
CASTER FORKS	SEALED BALL BEARINGS

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
