Specifications

Engine

Engine Type	400, 2-Stroke
Displacement	397cc
Cooling	Liquid
Cylinders	1
Bore x Stroke	85 x 70 mm
Lubrication	Electronic Injection
Ignition	Digitally Controlled CDI
Engine Stator Output	270W @ 3000 RPM
Fuel Delivery	Electronic Fuel Injected (EFI)
Exhaust	APV with Tuned Pipe, Pipe Sensor, Manifold & Stainless Steel Muffler
Fuel Capacity	11.7 gal
Oil System Capacity	3.25 qt
Coolant System Capacity	4.6 qt
Minimum Octane	91

Powertrain

Drive Clutch	CVTech Trailbloc
Driven Clutch	CVTech Invance
Drive System	Arctic Drive System
Brakes	Stealth Hydraulic Master Cylinder
Clutch Calibration	0-5,000 ft
Gearing	19/50
Chain Pitch	90
Track Drive Sprocket	9 Tooth, 2.52 Pitch, Involute
Reverse	Push-Button Engine

Suspensions

Front Suspension	Arctic Mountain Suspension (AMS)
Ski Shocks	Hydraulic Twin Tube
Sway Bar	N/A
Front Travel	7.2 in
Rear Suspension	Slide-Rail, Dual Shock & Adjustable Torsion Springs
Front Track Shock	Hydraulic Twin Tube
Rear Track Shock	Hydraulic Twin Tube
Rear Travel	10.7 in

Dimensions

Overall Chassis Length	115 in
Overall Chassis Width	44-45 in
Overall Chassis Height	45 in
Track Type	Hacksaw
Track Width	14 in
Track Length	121 in
Lug	1.00 in
Pitch	2.52 in
Ski Stance	37.5-38.5 in - Adjustable
Ski Type/Width	Trail - 6 in
Runner Type	Twin Split

Instrumentation

Type of Gauge	Powersport
Speedometer	Digital
Tachometer	Digital
Odometer	Digital
Fuel	Digital
Oil	Indicator Light
Coolant	Indicator Light
Clock	N/A
Battery Voltage	N/A
Altimeter	N/A
Hours	Digital

Features

Color	Black/Medium Green
Heat Exchanger	Front/Long Tunnel
Starter	Turnkey Electric Start
Handlebars	Hooked
Lighting	Halogen 1-Bulb
Seating	Mid-Size
Standard Accessories	Hand & Thumb Warmers, Standard Brake Disc, Standard Steering, Tether Switch
Windshield	4 in Low Height
