Specifications

POWERTRAIN - KOHLER KT725

ENGINE	KOHLER KT725
HORSEPOWER	22
FUEL CAPACITY	10 GAL
GROUND SPEED	9 MPH
DISPLACEMENT	725 CC
CRANKSHAFT	VERTICAL
COOLING SYSTEM	AIR
CLUTCH	ELECTROMAGNETIC
FUEL TYPE	GASOLINE
TRANSMISSION	HYDRO-GEAR ZT-3200

POWERTRAIN - KAWASAKI FT730

ENGINE	KAWASAKI FT730
HORSEPOWER	24
FUEL CAPACITY	10 GAL
GROUND SPEED	9 MPH
DISPLACEMENT	725 cc
CRANKSHAFT	VERTICAL
COOLING SYSTEM	AIR
CLUTCH	ELECTROMAGNETIC
FUEL TYPE	GASOLINE
TRANSMISSION	HYDRO-GEAR ZT-3200

GROUND FORCE DECK

CUTTING HEIGHT	1.5" - 4.5"
SPINDLE SPECS	FORGED ALUMINUM HOUSING W/ SEALED BALL BEARINGS
BLADE TIP SPEED	17,500 FT/MIN
DECK THICKNESS	10 GA W/11 GAUGE REINFORCED SPINDLE MOUNT
BLADE SPECS	203 STRAIGHTENED & HARDENED STEEL
DECK SIZE	44", 48", 54" & 60"

OPERATOR'S STATION

BACKREST	20" SEAT BACK
ROLLOVER PROTECTIVE STRUCTURES (UP/DOWN)	70" /46.3"
ARM REST	PADDED ARM RESTS
TRACK	6" LOCKING TRACK
COVER	DURABLE SEWN VINYL COVER
STEERING CONTROLS	1.5" DIA GRIPS, ADJUSTABLE, DAMPENED
PARKING BRAKE	INTEGRATED INTO STEERING LEVERS

CONSTRUCTION

FRONT TIRES	13" X 6.5" X 6" FLAT FREE
OVERALL LENGTH	74 3/4
REAR TIRES	44" & 48" DECKS - 23" X 8.5" . 54" & 60" DECKS - 22" X 12"
FEATURES	REINFORCED FORMED FRAME
FRAME GAUGE	7 GAUGE
OVERALL WIDTH (CHUTE UP)	44" - 44.75" . 48" - 48.75" . 54" - 54.75" . 60" - 60.75"
CASTER FORKS	3/8" FORMED
WEIGHT	44" - 950 LBS . 48" - 970 LBS · 54" - 1000 LBS . 60" - 1020 LBS
CASTER FORKS	SEALED BALL BEARINGS

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
