Specifications

Dimensions

Overall Length	94.5 in (240 cm)
Overall Width	47 in (119 cm)
Overall Height (w/o roof)	48.5 in (121 cm)
Overall Height (w/ roof)	71 in (178 cm)
Wheel Base	65.7 in (167 cm)
Front Wheel Track	35.5 in (90 cm)
Rear Wheel Track	38 in (97 cm)
Ground Clearance @ Differential	4 in (10 cm)

Power

Power Source	4-Cycle, 9.15 cu in (150 cc)
Valve Train	Single Cylinder OHV
Motor Type	Single Cylinder OHV, 4 Cycle, 9.15 cu in (150 cc)
Fuel System	Closed-Loop Electronic Fuel Injection
Horsepower (KW)	11.5 hp (8.6 kW) J1995 Standard
Electrical System	Brushless DC Internal Starter Generator
Batteries (qty/type)	One, 12 Volt Maintenance Free
Key or Pedal Start	Pedal
Air Cleaner	Industrial-Rated Dry Filter
Lubrication	Pressurized Oil System
Oil Filter	Removable Oil Screen
Cooling System	Air Cooled
Fuel Capacity	5.82 Gallon (22.03 L) Tank
Speed Controller	N/A
Drivetrain	Continuously Variable Transmission (CVT)
Transaxle	Differential with Helical Gears
Gear Selection	Forward-Reverse
Rear Axle Ratio	11.47:1 (Forward) 14.35:1 (Reverse)

Performance

Seating Capacity	4 Passenger
Dry Weight	676 lb (307 kg)
Curb Weight	692 lb (314 kg)
Vehicle Load Capacity	800 lb (364 kg)
Outside Clearing Circle	19 ft (5.8m)
Speed (Level Ground)	19.0 mph ± 0.5 mph (31.0 kph ± 0.8 kph)

Steering & Suspension

Steering	Double Ended Rack & Pinion
Suspension - Front	Independent A-Arm Coil Over Shock
Suspension - Rear	Mono-Lead Springs with Hydraulic Shocks
Service Brake	Rear Wheel Mechanical Self-Adjusting Drum
Parking Brake	Self-Compensating, Single Point Engagement
Tires	20 x 8 -10 Turf Tire on Black Wheel

Body & Chassis

Frame	Welded Steel with Powder-Coat Protection
Body & Finish	Injection Molded TPO

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
