Specifications

Dimensions

Overall Length	94.5 in (240 cm)
Overall Width	47.0 in (119 cm)
Overall Height (w/o roof)	47.5 in (126 cm)
Overall Height (w/ roof)	70 in (178 cm)
Wheel Base	66.0 in (168 cm)
Front Wheel Track	35.5 in (90 cm)
Rear Wheel Track	38 in (97 cm)
Ground Clearance @ Differential	4.5 in (11 cm)

Power

Power Source	48 Volt DC
Valve Train	N/A
Motor Type	48 Volt AC
Fuel System	N/A
Horsepower (KW)	4.4 hp (3.3 Kw) Continuous
Electrical System	48 Volt
Batteries (qty/type)	Four, 12 Volt Deep Cycle
Key or Pedal Start	Pedal
Air Cleaner	N/A
Lubrication	N/A
Oil Filter	N/A
Cooling System	N/A
Fuel Capacity	N/A
Battery Charger	48 VDC QE, 120 VAC, UL & CSA
Speed Controller	250 Amp Solid State Controller
Drivetrain	Motor Shaft Direct Drive
Transaxle	Limited Slip Differential
Gear Selection	Forward-Neutral-Reverse
Rear Axle Ratio	16.99:1

Performance

Seating Capacity	4 Passenger
Dry Weight	635 lb (257 kg)
Curb Weight	935 lb (411 kg)
Vehicle Load Capacity	800 lb (360 kg)
Outside Clearing Circle	19 ft (5.8 m)
Speed (Level Ground)	19 mph ± 0.5 mph (31 kph ± 0.8 kph)

Steering & Suspension

Steering	Double Ended Rack & Pinion
Suspension - Front	Independent A-Arm Coil Over Shock
Suspension - Rear	Mono-Lead Springs with Hydraulic Shocks
Service Brake	Induction Motor
Parking Brake	Automatic Electro-Magnetic
Tires	20 x 8 -10 Turf Tire on Black Wheel

Body & Chassis

Frame	Welded Steel with Powder-Coat Protection
Body & Finish	Injection Molded TPO

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
