Specifications

Dimensions

Overall Length	115.6 in (293 cm)
Overall Width	48.5 in (123 cm)
Overall Height (w/o Roof)	52.5 in (133 cm) (Top of Steering Wheel)
Overall Height (w/ Roof)	83.0 in (210 cm)
Wheel Base	65.5 in (166 cm)
Front Wheel Track	38.5 in (98 cm)
Rear Wheel Track	38.5 in (98 cm)
Ground Clearance	6 in (15 cm)

Power

Power Source	4-Cycle 24.5 in³ (401 cc)
Valve Train	Single Cylinder OHV
Fuel System	Closed-Loop Electronic Fuel Injection
Horsepower/kW	13.5 hp (10.1 kW) Exceeds SAE J1940 Standard
Electrical System	Starter / Generator. Solid State Regulator
Key/Pedal Start	Pedal
Air Cleaner	Replaceable Dry Cartridge
Lubrication	Pressurized Oil System
Cooling System	Air Cooled
Oil Filter	Spin-On
Fuel Capacity	5.96 Gallon (22.6 L)
Speed Controller	N/A
Drivetrain	Automatic, Continuously Variable Transmission (CVT)
Transaxle	Differential with Helical Gears (Gas Only)
Gear Selection	Dash Mounted Forward-Neutral-Reverse
Rear Axle Ratio	11.47:1 (Forward) 14.35:1 (Reverse)
Batteries (Qty/Type)	12-Volt Maintenance-Free (525 CCA, 85 minute reserve)

Performance

Dry Weight	1061 lb (481 kg) (Without Battery)
Curb Weight	1101 lb (499 kg)
Load Capacity	800 lb (360 kg)
Outside Clearance	22 ft (6.7 m)
Speed	Up to 19 mph ± 0.5 mph (Up to 30.6 kph ± 0.8 kph)
Range	N/A

Steering & Suspension

Steering	Self-Compensating Rack and Pinion
Suspension	Leaf Springs with Hydraulic Shock Absorbers
Service Brake	Rear Wheel Mechanical Self-Adjusting Drum
Parking Brake	Self-Compensating, Single Point Engagement
Tires	Paramount M/T Tire on 14” Black Steel Wheel

Body & Chassis

Frame	Welded Steel with E-Coat & DuraShieldTM Powder Coat
Body & Finish	Injection Molded TPO

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
